RZ2225 Thin Client

Highly Secure and Compact Design, Supporting 4K Three Display and Advanced Configurations to Meet Every Needs

RZ2225

Thin Client

8 Editions

Leadtek is specialized in designing and manufacturing truly astounding graphics performance, outstanding power efficiency, and remarkably reliable endpoint devices for VDI (Virtual Desktop Infrastructure) applications.

Ultra-Thin Client is targeted to users who request productivity-maximizing features and full ISV provider compatibility, including Citrix, VMware and Microsoft You can choose the processing power appropriate for your productivity needs, whether it's for graphics-intensive design or everyday office-based tasks.

  • Apply AMD R2314 System-on-Chip low-power integrated solution
  • Three 4K UHD
  • Five USB (two USB 3.2, one USB3.2/Type-C ,and two USB 2.0) peripherals
  • DDR4 dual-channel SDRAM system memory and optional integrated smart card reader
  • Support Ethernet LAN or SFP Fiber, and optional 2.4G, 5G, and 6G tri-band wireless network

Compact, Fan-less and Green Design with Low-Power SoC

Leadtek AMD Ryzen R2314 Thin Client is a book-size desktop device that applies low-power SoC with a very low power consumption of 15 watts and no need of fan for cooling. Additionally, we give it super slim look and slim design is perfect for users with limited working space. Thanks to the space-saving and noiseless features, users will hardly notice it on their office desks. Optional VESA Mount kit enables users to mount Thin Client behind the monitor, cleaning up more space for daily works.

Leadtek Device Management Software and Thin Client OS
Keep Your Client Deployment Simple

Leadtek (Ultra-) Thin Client with LvOS (Leadtek Thin Client OS) can be managed by DMS (Leadtek Device Management Software), a free web-based management tool that allows administrators:

  • Centrally and remotely access and update the configuration of your client devices
  • Effectively apply the same configuration data to groups of devices
  • Easy deployment, troubleshooting, and view status information
  • Update settings and firmware via easy-to-use interface

LvOS is a virus-proof Linux OS that has no attraction to the malware attacks. With DMS security control, end-user misconfiguration is totally blocked. LvOS and DMS can further streamline the already minimal management of a VDI infrastructure.

  Three Display

Support up to
three 3840x2160 UHD

Support up to three 3840x2160 UHD, perception-free video outputs, and five USB (two USB 3.2 ,one USB3.2/Type-C and two USB 2.0) peripherals allows PC/workstation and server relocation to the datacenter or computer room without compromising end user experience or productivity.

Network Adaptability with Gigabit Ethernet, SFP Fiber, and Optional Wireless

Leadtek (Ultra-) Thin Client features a high degree of connectivity with your choice of embedded networking interface in 10/100/1000 Mbps Ethernet LAN or 100/1000 Mbps SFP Fiber. It also supports optional tri-band WiFi and Bluetooth wireless so you can get connected when you need to.

DDR4 dual-channel
SDRAM system memory

Support dual-channel DDR4 memory, up to 2677 MT/s high-speed data transfer rate

Feature Integrated Smart Card Reader Authentication

IT system requires authentication of users. This identification is commonly done with passwords. Because of the value and confidentiality of information in the financial institutions as well as enterprises and governments, protecting intellectual property, IT system, and employee identity credentials has always been a priority. High-performance Smart Card Reader that is compliant with all industry standards and is compatible with virtually any contact smart card and a variety of applications.

Comparison

Product EL2115 Ultra-Thin Client EL4115 Ultra-Thin Client RZ2215 Ultra-Thin Client RZ2225 Thin Client RZ4415 Thin Client RZ4425 Thin Client
Processor Intel x6211E SOC (1.3-3.0GHz dual-core) Intel x6413E SOC (1.5-3.0GHz quad-core) AMD R1305G SOC (1.5-2.8GHz dual-core) AMD R2314 SOC (2.1-3.5 GHz quad-core) AMD V1605B SOC (2.0-3.6 GHz quad-core) AMD R2514 SOC (2.1-3.7 GHz quad-core)
RAM Onboard 4GB/8GB LPDDR4 Onboard 4GB/8GB LPDDR4 DDR4-2400, up to 16GB DDR4-2677(no ECC), 8GB DDR4-2400, up to 16GB DDR4-2677(no ECC), 8GB
Storage Non-removable eMMC (default 8GB or 32GB) Non-removable eMMC (default 8GB or 32GB) Non-removable eMMC, up to 32GB Non-removable eMMC, up to 128GB SSD-M.2 (SATA), up to 32GB Non-removable eMMC, up to 128GB or SSD-M.2 (SATA), up to 128GB
Video Output Three DisplayPort* Three DisplayPort* Two DisplayPort Three DisplayPort* Four DisplayPort Four DisplayPort
Maximum Resolution 4096x2160 UHD @ 60Hz (DP) 4096x2160 UHD @ 60Hz (DP) 3840x2160 UHD @ 60Hz (DP) 3840x2160 UHD @ 60Hz (DP) 3840x2160 UHD @ 60Hz (DP) 3840x2160 UHD @ 60Hz (DP)
USB Peripherals Five (2x USB 3.2 Gen2, 1x Type-C, 2x USB 2.0) Five (2x USB 3.2 Gen2, 1x Type C, 2x USB 2.0) Five USB (two USB 3.2, one USB 3.0/Type-C, and two USB 2.0) Five (2x USB 3.2 Gen2, 1x Type C, 2x USB 2.0) Six (4x USB 3.2, 2x USB 2.0) Seven (4x USB 3.2, 1x USB 3.2/Type-C,2x USB 2.0)
Audio Headphones / Microphone / Speaker (internal) Headphones / Microphone / Speaker (internal) Headphones / Microphone / Speaker (internal) Headphones / Microphone / Speaker (internal) Headphones / Microphone / Speaker (internal) Headphones / Microphone / Speaker (internal)
Network Connector RJ45 or SFP Fiber, optional wireless RJ45 or SFP Fiber, optional wireless RJ45 or SFP Fiber, optional wireless RJ45 or SFP Fiber, optional wireless RJ45 or SFP Fiber, optional wireless RJ45 or SFP Fiber, optional wireless
Authentication Optional smart card reader Optional smart card reader Optional smart card reader Optional smart card reader Optional smart card reader Optional smart card reader
OS Linux, Windows Linux, Windows Linux, Windows Linux, Windows Linux, Windows Linux, Windows
Thermal Cooling Solution Passive heat sink Passive heat sink Passive heat sink Passive heat sink Active fan sink or Passive heat sink Active fan sink or Passive heat sink
Kensington Security Slot Yes Yes Yes Yes Yes Yes
VESA Mount Support Yes Yes Yes Yes Yes Yes
Device Physical Dimensions 6.7 (height) x 5.2 (length) x 1.2 (thinness) inches without stand
Contact us for details on our enclosures and their dimensions		 6.7 (height) x 5.2 (length) x 1.2 (thinness) inches without stand
Contact us for details on our enclosures and their dimensions		 6.7 (height) x 5.2 (length) x 1.2 (thinness) inches without stand
Contact us for details on our enclosures and their dimensions		 7.81 (height) x 6.19 (length) x 2.44 (thinness) inches without stand
Contact us for details on our enclosures and their dimensions		 7.18 (height) x 7.16 (length) x 1.89 (thinness) inches without stand
Contact us for details on our enclosures and their dimensions		 7.18 (height) x 7.16 (length) x 1.89 (thinness) inches without stand
Contact us for details on our enclosures and their dimensions
TAA Compliance Yes Yes Yes Yes Yes Yes
Optional Wireless 2.4G and 5G dual-band 802.11 a/b/g/n/ac Wi-Fi (2T/2R) + Bluetooth 5.0 integrated wireless (Intel WiFi 5- AC 9260) with external dual antennas 2.4G, 5G, and 6G tri-band 802.11 a/b/g/n/ac/ax Wi-Fi (2T/2R) + Bluetooth 5.3/5.0
integrated wireless with external dual antennas		 2.4G, 5G, and 6G tri-band 802.11 a/b/g/n/ac/ax Wi-Fi (2T/2R) + Bluetooth 5.3/5.0
integrated wireless with external dual antennas		 2.4G, 5G, and 6G tri-band 802.11 a/b/g/n/ac/ax Wi-Fi (2T/2R) + Bluetooth 5.3/5.0
integrated wireless with external dual antennas
Package Content (Ultra-) Thin Client
19V power adapter and power cord
Ethernet cable (optional)
Quick installation guide
Operating / Storage Environment Temperature
  • Operational: 0 to 40 degree C
  • Storage: -20 to 70 degree C

*Note: EL4115/EL2115/RZ2225 support two display port plus one display port over USB-C
