TERA2240 PCoIP Host Card

  • Add to Compare

Product Model
  • TERA2240 host card (RJ45 edition)
  • TERA2240 host card (SFP Fiber edition)

TERA2240 PCoIP remote acceleration cards can be added to any existing PC or workstation to enable field-proven high-end 1:1 session leveraging PCoIP protocol graphics and desktop performance. It’s the only hardware remote solution which allows high-end 3D applications with dedicated GPUs that is not available when using virtualized desktops.

Powerful Collaboration with High Performance Graphics Card

No matter you are a 3D game artist, an animation modeling designer, movie editor, or mechanical engineer, your workstation which is embedded the workstation card or other high-performance graphics card must offer high level of interactivity while enabling unprecedented performance, features and photo-realistic image quality. PCoIP host card series is the only hardware remote solution which allows you continue using your current graphics card to deliver the fastest application performance and the highest quality workstation graphics.

Hardware Advantages over Software Codec

PCoIP hardware acceleration host card optimizes CPU loading, network loading, and user experience at once, while other software remote solutions optimize one at the expense of the others.

Features
  • Remoted to a PCoIP zero client or a Teradici PCoIP Software Client
  • All you need is a free PCIe slot and a graphics card
  • High Security and Privacy by locating data in the datacenter
  • Completely OS Independent
  • All applications run as normal
  • Manages complexity and reduce cost by facilitating centralized management

Brochure Download


Model TERA1202 Series TERA2240 Series TERA2220 Series
Max Number of Displays 2 4 2
Processor TERA1202 TERA2240 TERA2220
Form Factor Low Profile ATX Low Profile
Board Physical Dimensions 2.713 inches (height) X 6.6 inches (length), single slot 4.376 inches (height) X 6.6 inches (length), single slot 2.713 inches (height) X 6.6 inches (length), single slot
Bus Type PCI Express x1 (compatible with any xPCIe slots: x1, x4, x8, x16)
Imaging Performance 100 Mpps 250 Mpps 130 Mpps
Maximum Resolution Two 1920x1200 Two 2560x1600 or
Four 1920x1200
One 2560x1600 or
Two 1920x1200
Max Application Frame Rate (with PCoIP Zero clients) 60 fps 60 fps 60 fps
PCIe Video Ports (connect to Graphics outputs) One DMS-59 (with DVI adapter) Four mini-DisplayPort Two mini-DisplayPort
Memory Type 128 MB XDR

512 MB DDR3 with ECC

Typical Board Power 13W 13W 13W
Encryption AES-128/Salsa256
Suite B Ciphers (Workstation)
AES-128/AES-256
Suite B Ciphers (Workstation)
Recommended Zero Client Endpoints for Full Functionality TERA1100 TERA2140 TERA2321 or TERA2140
Connectors 59-pin DMS-59 connector (supports dual DVI-D) Four mini-DisplayPort connectors Two mini-DisplayPort connectors
Ethernet connector or Fiber connector Ethernet connector or Fiber connector Ethernet connector or Fiber connector
Power Button Cable connector (optional for Remote Power Management) Power Button Cable connector (optional for Remote Power Management) Power Button Cable connector (optional for Remote Power Management)
Standalone Mode Power connector
Thermal Cooling Solution Passive heat sink
Operating System Support Completely operating system independent
System Requirements PCI Express compliant motherboard with one x1/x4/x8/x16 slot (Full height for TERA2240 and full/half height for TERA1202/2220)
PC/workstation with 1 or 2 graphics cards
For 2560x1600 resolution, graphics card port must be DisplayPort (dual-link DVI is not supported)
10/100/1000 Mbps Ethernet LAN or 100/1000 Mbps Fiber switch/router
Package Content PCoIP host card PCoIP host card PCoIP host card
One dual DVI to DMS-59 cable One to four DVI to mini-DisplayPort cables (Optional) One or two DVI to mini-DisplayPort cables (Optional)
Ethernet cable x 1 (Optional) One to four DisplayPort to mini-DisplayPort cables (Optional) One or two DisplayPort to mini-DisplayPort cables (Optional)
Power Button cable x 1 (optional for Remote Power Management) One to four mini-DisplayPort to mini-DisplayPort cables (Optional) One or two mini-DisplayPort to mini-DisplayPort cables (Optional)
Additional Low Profile bracket x 1 Power Button cable x 1 (optional for Remote Power Management) Power Button cable x 1 (optional for Remote Power Management)
Quick installation guide Quick installation guide Additional Low Profile bracket x 1
    Quick installation guide

Brochure Download

TERA2240 PCoIP Host Card
OS Language Version Description
Utility
English2.5.1
( 2017/6/9 )
Supporting Models :TERA2 Zero Clients with firmware 5.0 or higher
PCoIP Management Console (PCoIPMC) enables administrators to centrally manage a PCoIP deployment. more
Total size: [ 1441058 KB ]
download
English1.10.8
( 2017/1/16 )
Supporting Models :TERA2 and TERA1 Host Cards and Zero Clients
PCoIP Management Console (PCoIPMC) enables administrators to centrally manage a PCoIP deployment. more
Total size: [ 501553 KB ]
download
Audio driver

XP
Vista
7
8
English1.2.1
( 2016/3/22 )
Supporting Models :The PCoIP Component Installer is supported on the following operating systems: - Microsoft Windows XP 32 bit - Microsoft Windows 7 32 bit - Microsoft Windows 7 64 bit - Microsoft Windows 8 64 bit
Teradici Virtual Audio Driver more
Total size: [ 1076 KB ]
download
Applications
English2.2
( 2016/2/16 )
Supporting Models :TERA2 Zero Clients running firmware 4.7.1 or later
The Teradici PCoIP Workstation Access Software is a software bundle that includes two host agents for different PCoIP deployment scenarios. The deskside scenario facilitates deployments that have a workstation with local monitor(s) attached. The datacenter/cloud scenario facilitates deployments that have a workstation (physical, virtualized, or in the cloud) with NO local monitor(s) attached. more
Total size: [ 19081 KB ]
download
English2.3
( 2016/2/16 )
Supporting Models :TERA2 Zero Clients running firmware 4.7.1 or later
The Teradici PCoIP Workstation Access Software is a software bundle that includes two host agents for different PCoIP deployment scenarios. The deskside scenario facilitates deployments that have a workstation with local monitor(s) attached. The datacenter/cloud scenario facilitates deployments that have a workstation (physical, virtualized, or in the cloud) with NO local monitor(s) attached. more
Total size: [ 19359 KB ]
download
Firmware
Multilanguage5.5.1
( 2017/5/10 )
Supporting Models :TERA2 Zero Clients
Firmware 5.5.1 is only applicable to TERA2 Zero Clients. For TERA2 Host Cards and TERA1 products, firmware 4.9.0 is the latest firmware release.  Either zero client firmware 4.7.x or 4.8 must be used as the staging firmware prior to upgrading to firmware 5.5.1.
Total size: [ 30865 KB ]
download
Multilanguage4.8.2
( 2016/9/28 )
Supporting Models :TERA2 Zero Clients
Firmware 4.8.2 is only applicable to TERA2 Zero Clients. For TERA2 Host Cards and TERA1 products, firmware 4.9.0 is the latest firmware release.  If zero clients have firmware 4.2.0 or earlier installed, then you will need to install firmware 4.6.0 in order to upgrade to 4.8.2.
Total size: [ 34341 KB ]
download
Multilanguage4.8.0
( 2015/4/8 )
Supporting Models :TERA2 Zero Clients
Firmware 4.8.0 is only applicable to TERA2 Zero Clients. For TERA2 Host Cards and TERA1 products, firmware 4.9.0 is the latest firmware release.  If zero clients have firmware 4.2.0 or earlier installed, then you will need to install firmware 4.6.0 in order to upgrade to 4.8.0.
Total size: [ 41226 KB ]
download
Multilanguage4.6.0
( 2014/10/7 )
Supporting Models :TERA2 Host Cards and Zero Clients
This is a major release 4.6.0 installed on both the TERA2 Host and Zero Client. more
Total size: [ 19340 KB ]
download

TERA2240 PCoIP Host Card
Language Version Description
User's Manual
EnglishIssue 13
( 2016/5/31 )
This Administrators Guide helps you through the process to set up and configure your TERA2 products.
Total size: [ 10309 KB ]
download
Quick Guide
MultilanguageA
( 2012/11/13 )
Supporting Models :TERA2 Host Cards
This Quick Start Guide will help you configure your TERA2 host card.
Total size: [ 4218 KB ]
download
MultilanguageA
( 2016/3/2 )
Supporting Models :TERA2 Zero Clients
This Quick Start Guide will help you configure your TERA2 zero client.
Total size: [ 2940 KB ]
download
DM
(繁體中文)2015
( 2015/5/4 )
PCoIP產品型錄
Total size: [ 1757 KB ]
download
English2017
( 2017/5/12 )
PCoIP product brochure
Total size: [ 3803 KB ]
download
Deplyment Guide
EnglishIssue 3
( 2013/1/31 )
Using PCoIP Host cards with VMware View more
Total size: [ 1405 KB ]
download
English2.6
( 2016/11/30 )
Supporting Models :PCoIP host/client
PCoIP Protocol Virtual Network Design Checklist more
Total size: [ 536 KB ]
download
