NVIDIA Quadro GP100

  • Add to Compare

NVIDIA Quadro GP100

World's Most Advanced Visual
Computing Accelerator



  • Pascal GPU
  • 3584 CUDA NVIDIA CUDA® Cores
  • 16 GB HBM2 GPU Memory
  • Up to 717 GB/s Memory Bandwidth
  • PCI Express 3.0 System Interface
  • 5.2 TFLOPS FP64 Performance
  • 10.3 TFLOPS FP32 Performance
  • 20.7 TFLOPS FP16 Performance
  • 235W Max Power Consumption
  • 4 x DP 1.4 + DVI-D DL Display Conntectors
  • 4x 4096x2160 @120Hz Display Resolution
  • 4x 5120x2880 @60Hz Display Resolution
  • Support ECC Protection
  • Support Quadro Sync II
  • Support Quadro NVLink Bridge


Mixed-Precision Computing

Double the throughput and reduce storage requirements with 16-bit floating point precision computing to enable the training and deployment of larger neural networks.

High Speed HBM2 Memory

Built with 16GB of the industry’s fastest graphics memory (717 GB/s peak bandwidth), Quadro GP100 is the ideal platform for latency-sensitive applications handling large datasets.

NVLink High Speed Interface

Connect a pair of Quadro GP100 cards with NVLink to increase the effective memory footprint and scale application performance by enabling GPU-to-GPU data transfers at rates up to 80 GB/s (bidirectional)

Support Quadro Sync II

Synchronize the display and image output of up to 32 displays from 8 GPUs (connected through two Sync II boards) in a single system, reducing the number of machines needed to create an advanced video visualization environment.

Quadro High-End Series Performance

Advanced Display Features

DisplayPort 1.4
●DP 1.4 provides twice the bandwidth of the previous generation
●Drive up to four 5K displays simultaneously
●HDR support displays 2x the visible colors resulting in brighter, more saturated images

Multiple Display
●Power up to Four 5K Displays
●Synchronize up to 8 GPUs per system with Quadro Sync II cardv

Virtual Reality
●2x Geometry Throughput
●Richer, more lifelike VR experiences

Mosaic Technology, available only on Quadro

Quadro Enable Massive Visualization

Two Quadro Sync II cards can be connected to synchronize up to 8 GPUs
per system to provide up to 32 synchronized displays per system!

Scale Up Application Performance with NVIDIA NVLink Technology

3D Graphics Architecture

  • 64x full scene antialiasing (FSAA)/128xFSAA in NVIDIA SLI® Mode
  • Up to 16 K x 16 K texture and render processing
  • Support Shader Model 5.1/OpenGL 4.5/DirectX 12.0/Vulkan 1.0
  • 32-bit per-component floating point texture filtering and blending
  • 16x angle independent anisotropic filtering
  • Anisotropic filtering improves the clarity and crispness of textured objects in rendering. Textures are images containing various types of data such as color, transparency, reflectivity, and bumps (normals) that are mapped to an object and processed by the GPU in order to give it a realistic appearance on your screen

Top Professional Applications Certified


VR Ready for Professional VR

CREATE IT.

VRWorks™ is a comprehensive suite of APIs, libraries,and engines that enable application and headset developers to create amazing Virtual Reality experiences.
VRWorks enables a new level of presence by bringing physically realistic visuals, sound, touch interactions, and simulated environments to Virtual Reality.

Industry Solutions

NVIDIA Packaging and Accessories



  • GP100 Graphics Board
  • DP-DVI*3 Adaptors
  • 3D Stereo Connector
  • Auxiliary Power Cord
  • Driver Disc
  • Quick Installation Guide
  • Warranty Card
  • Support Guide

CUDA Parallel Processing cores

3584

Frame Buffer Memory

16 GB HBM2 ECC

Peak Double Precision (FP64) Performance

5.2 TFLOPs

Peak Single Precision(FP32) Performance

10.3 TFLOPs

Peak Half Precision (FP16) Performance

20.7 TFLOPs

Memory Interface

4096-bit

Memory Bandwidth

717 GB/s

Max Power Consumption

235 W

Graphics Bus4

PCI Express 3.0 x16

Display Connectors

DP 1.4 (4), DVI-D DL (1)

Form Factor

4.4” H x 10.5” L Dual Slot

Product Weight

815g

Thermal Solution

Active

CNVIDIA® 3D Vision® and 3D Vision Pro

Support via 3 pin mini DIN

Frame lock Compatible (with Quadro Sync II)
Multi-GPU Scalability NVLink (2-way)
