WinFast GS2045T

  • Optimized for AI/Deep Learning GPU peering
  • Supports up to 4 double-wide GPU cards
  • Supports up to 4TB DDR4 3200MHz memory

Key Features


  • Dual Socket SP3, support AMD EPYC™ 7002/7003 Series Processors(up to 200W TDP)
  • 16 DIMMs; up to 4TB 3DS ECC DDR4-3200MHz† RDIMM/LRDIMM
  • 4 PCI-E 4.0 x16 slots (FHFL)
    4 PCI-E 4.0 x8 slots
    2 PCI-E 4.0 x16 low-profile slots
  • Support up to 4 pcs of Double-width GPUs or 8 pcs of Single-width GPUs
  • Dual 10GBase-T LAN ports
  • 8 Hot-swap 3.5" SATA/U.2 NVMe drive bays
  • 5x 8cm heavy duty fans with optimal fan speed control
  • 2200W (1+1) Redundant Platinum Level (94%) power supply with PMBus

Multiple GPU support

WinFast GS2045T features a powerful GPU architecture that supports up to 4 double-width GPUs in a 2U server, including NVIDIA® A40/A30/A10/A6000, Tesla V100s/V100/T4, Quadro RTX8000/RTX6000®, enable scaling of performance in order to meet the demands of AI, high-performance computing, and 3D rendering applications.

3rd Gen AMD EPYC™ High Frequency Processors

Workload Performance Leadership

Powering solutions in the Cloud, on-prem or off-prem, in containers, or VMs. Whether on bare metal or HCI, AMD EPYC™ 7003 Series provides outstanding performance across the wide spectrum of industry standard applications. As the leader in high-performance computing, AMD continues to raise the bar for data center computing delivering on its continuous roadmap execution and commitment to innovation.

Make the most of your
enterprise software investment

A balanced and optimized IT infrastructure, workload acceleration, and data protection is a must for enterprises to be competitive. AMD has been on the forefront of solving these challenges by delivering leadership innovations. The new AMD EPYC™ 7Fx2 Series Processors provide businesses advanced security features and ground-breaking performance with Hyper Converged Infrastructure (HCI), Databases (DB) and Commercial High Performance Computing (HPC) applications – enabling faster business insights and time to volume while helping optimize TCO.

PCIe® 4.0 doubles the data transfer speed over the previous generation

PCIe 4.0 delivers double the I/O performance over PCIe 3.0. You can use 128 lanes of I/O to double the network bandwidth that ties together HPC clusters and satisfies voracious needs for east-west bandwidth. For other application needs and in virtualized environments, you can connect with higher speed to GPU accelerators, NVMe drives.

Cooling System

High efficiency cooling system-5x Heavy duty fans with Optimal Fan Speed Control, for less power and ensure a stable environment and availability 24/7.

SATA vs NVMe

Up to 5.3X performance than SATA

System Health Monitoring

The system has an onboard Baseboard Management Controller (BMC)
chip that supports system health monitoring.

Onboard Voltage Monitors

The onboard voltage monitor will continuously scan crucial voltage levels. Once a voltage becomes unstable, it will give a warning or send an error message to the IPMI WebGUI and IPMIView. Real time readings of these voltage levels are all displayed in IPMI.

Fan Status Monitor with Firmware Control

The system health monitor embedded in the BMC chip can check the RPM status of the cooling fans. The CPU and chassis fans are controlled via lPMI.

Environmental Temperature Control

System Health sensors in the BMC monitor the temperatures and voltage settings of onboard processors and the system in real time via the IPMI interface. Whenever the temperature of the CPU or the system exceeds a user-defined threshold, system/CPU cooling fans will be turned on to prevent the CPU or the system from overheating.

System Resource Alert

This feature is available when used with SuperDoctor 5. SuperDoctor 5 is used to notify the user of certain system events. For example, you can configure SuperDoctor 5 to provide you with warnings when the system temperature, CPU temperatures, voltages and fan speeds go beyond a predefined range3.

Optional software

Applications


Manufacturing

Manufacturing

Model, simulate, test, and improve products like never before. With WinFast Workstation manufacturers can design and bring innovative products to market faster.
Media & Entertainment

Media & Entertainment

From pre-vis to post-production, the industry's most critically-acclaimed feature films require the latest technological advancements. WinFast Workstation works behind the scenes giving you the precision and power to tell remarkable stories.
Architecture

Architecture, Engineering and Construction

Workflows in the architecture, engineering, and construction (AEC) space are in transformation. Leading-edge technologies, powered by WinFast Workstation , are enabling AEC teams to optimize design workflows and build for the future.

AI Applications


CONSUMER INTERNET

CONSUMER INTERNET

Ad Personalization Click Through Rate Optimization Churn Reduction.
OIL & GAS

OIL & GAS

Sensor Data Tag Mapping Anomaly Detection Robust Fault Prediction.
FINANCIAL SERVICES

FINANCIAL SERVICES

Claim fraud Customer Service Chatbots/Routing Risk Evaluation.
MANUFACTURING

MANUFACTURING

Remaining Useful Life Estimation Failure Prediction Demand Forecasting.
HEALTHCARE

HEALTHCARE

Improve Clinical Care Drive Operational Effeciency Speed Up Drug Discovery.
TELECOM

TELECOM

Detect Network/Security/Anomalies Forecasting Network Performance Network Resource Optimization (SON).
RETAIL

RETAIL

Supply Chain and Inventory Management Price Management/Markdown Optimization Promotion Prioritization and Ad Targeting.
AUTOMOTIVE

AUTOMOTIVE

Personalization & Intelligent Custoemr Interactions Connected Vehicle Predictive Maintenance Forecasting, Demand and Capacity Planning.
Smart Home

SMART HOME

AI Speaker, Lighting, Security AI Appliances, Thrtmostat AI Vauums.

Leadtek AI Management Software

Leadtek GPU Docker Management System (GDMS) is a Docker-based GPU resource allocation and management software. GDMS uses an intuitive and graphical user interface to centrally manage AI and big data projects and development resources for universities/schools, research institutions, and corporations.

Processor
CPU
Dual AMD EPYC™ 7002/7003 Series Processors
Socket SP3
Supports CPU TDP up to 240W
Up to 128 Cores (64 per CPU)

System Memory
Memory Capacity
16 DIMM slots
Up to 4TB 3DS ECC DDR4-3200MH RDIMM/LRDIMM
Memory Type 3200MHz ECC DDR4 RDIMM/LRDIMM

On-Board Devices
Chipset System on Chip (SoC)
SATA SATA3 (6Gbps)
Network 2 10GBase-T LAN ports (Intel X550-ATX)
IPMI
Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Graphics ASPEED AST2500 BMC

Input / Output
SATA 8 SATA3 (6Gbps) ports
LAN
2 RJ45 GBase-T LAN ports
1 RJ45 Dedicated IPMI LAN port
USB 4 USB 3.2 Gen1 ports
Video 1 VGA Connector

Form Factor
2U Rackmountable with Rail kit

Dimensions
Height 3.43"(87mm)
Width 17.25"(438.4mm)
Depth 32.71"(831mm)
Weight
Net Weight: 44.8 lbs (20.3 kg)
Gross Weight: 73 lbs (33.1 kg)

Drive Bays / Storage
Hot-swap Up to 8x 3.5" SATA/NVMe drive bays

Expansion Slots
PCI-Express
4 FH/FL PCIe Gen 4.0 x16/x8 slots (MUX pairs with adjacent x8 slots)
4 FH/FL PCIe Gen 4.0 x0/x8 slots (MUX pairs with adjacent x16 slots)
2 Low Profile PCIe x16 Gen 4.0 slots

System Cooling
Fans 5pcs 8cm Heavy duty fans with optimal fan speed control

Power Supply
Power 2200W (1+1) Redundant Platinum Level (94%) Power Supplies with PMBus

OS Compatibility
OS
Ubuntu 18.04 LTS (x64) or later
Ubuntu 20.04 LTS (x64) or later
Red Hat Enterprise Linux 7.6-8.x
Windows Server 2016
Windows Server 2019

Operating Environment
RoHS RoHS Compliant
Environmental Spec.
Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F)
Non-operating Temperature: -40°C to 70°C (-40°F to 158°F)
Operating Relative Humidity: 8% to 90% (non-condensing)
Non-operating Relative Humidity: 5% to 95% (non-condensing)
