WinFast GS4830AT

  • Optimized for AI/Deep Learning GPU peering
  • Supports 10 double-wide GPU cards
  • Single Root System for excellent GPU peer to peer communication with sufficient CPU to GPU throughput

Optimized for

  • AI / Deep Learning
  • Scientific Research
  • 3D Rendering Farm
  • Astrophysics, Business Intelligence

Key Features


  • Dual Socket P (LGA 3647) support 2nd Gen. Intel® Xeon® Scalable processors (Cascade Lake/Skylake)
  • 24 DIMMs; up to 6TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM,supports Intel® Optane™ DCPMM
  • 11 PCI-E 3.0 x16 (FH, FL) slots
    1 PCI-E 3.0 x8 (FH, FL in x16 slot)
  • Support up to 10 pcs of Double-width GPUs
  • Dual 10GBase-T LAN ports
  • Up to 24 Hot-swap 2.5" drive bays; 8x 2.5" SATA drives supported with included H/W
    2x 2.5" NVMe drives supported with included H/W
    1 NVMe based M.2 SSD
  • 8 Hot-swap 92mm cooling fans
  • 2000W (2+2) Redundant Power Supplies Titanium Level (96%+)

SATA vs M.2 NVMe

HPC is a fundamental pillar of modern science. From predicting weather to discovering drugs to finding new energy sources, researchers use large computing systems to simulate and predict our world. AI extends traditional HPC by allowing researchers to analyze large volumes of data for rapid insights where simulation alone cannot fully predict the real world.

V100 is engineered for the convergence of AI and HPC. It offers a platform for HPC systems to excel at both computational science for scientific simulation and data science for finding insights in data. By pairing NVIDIA CUDA® cores and Tensor Cores within a unified architecture, a single server with V100 GPUs can replace hundreds of commodity CPU-only servers for both traditional HPC and AI workloads. Every researcher and engineer can now afford an AI supercomputer to tackle their most challenging work

True Peer-to-Peer 8 GPU System

  • Single Root PCI-E Complex design for 8 GPU Cards
  • Latest PCI-E switch provides more PCI-E lanes and bandwidth
  • P2P communications supports between GPU 0/1/2/3/4/5/6/7
  • Configured for scaling with GPUDirect RDMA

GPUDirect RDMA (remote direct memory access) enables network devices to directly access GPU memory, bypassing CPU host memory altogether.

  • Accelerated communication with network and storage devices
  • Peer-to-Peer transfers and memory access between GPUs
  • Eliminate CPU bandwidth and latency bottlenecks using remote direct memory access (RDMA) transfers between GPUs and other PCI-E devices

System Health Monitoring

The system has an onboard Baseboard Management Controller (BMC) chip that supports system health monitoring.

Onboard Voltage Monitors

The onboard voltage monitor will continuously scan crucial voltage levels. Once a voltage becomes unstable, it will give a warning or send an error message to the IPMI WebGUI and IPMIView. Real time readings of these voltage levels are all displayed in IPMI.

Fan Status Monitor with Firmware Control

The system health monitor embedded in the BMC chip can check the RPM status of the cooling fans. The CPU and chassis fans are controlled via lPMI.

Environmental Temperature Control

System Health sensors in the BMC monitor the temperatures and voltage settings of onboard processors and the system in real time via the IPMI interface. Whenever the temperature of the CPU or the system exceeds a user-defined threshold, system/CPU cooling fans will be turned on to prevent the CPU or the system from overheating.

System Resource Alert

This feature is available when used with SuperDoctor 5. SuperDoctor 5 is used to notify the user of certain system events. For example, you can configure SuperDoctor 5 to provide you with warnings when the system temperature, CPU temperatures, voltages and fan speeds go beyond a predefined range3

Applications


CONSUMER INTERNET

CONSUMER INTERNET

Ad Personalization Click Through Rate Optimization Churn Reduction.
OIL & GAS

OIL & GAS

Sensor Data Tag Mapping Anomaly Detection Robust Fault Prediction.
FINANCIAL SERVICES

FINANCIAL SERVICES

Claim fraud Customer Service Chatbots/Routing Risk Evaluation.
MANUFACTURING

MANUFACTURING

Remaining Useful Life Estimation Failure Prediction Demand Forecasting.
HEALTHCARE

HEALTHCARE

Improve Clinical Care Drive Operational Effeciency Speed Up Drug Discovery.
TELECOM

TELECOM

Detect Network/Security/Anomalies Forecasting Network Performance Network Resource Optimization (SON).
RETAIL

RETAIL

Supply Chain and Inventory Management Price Management/Markdown Optimization Promotion Prioritization and Ad Targeting.
AUTOMOTIVE

AUTOMOTIVE

Personalization & Intelligent Customer Interactions Connected Vehicle Predictive Maintenance Forecasting, Demand and Capacity Planning.

Processor

CPU
  • Dual Socket P (LGA 3647)
  • 2nd Gen. Intel® Xeon® Scalable Processors (Cascade Lake/Skylake)
  • 3 UPI up to 10.4GT/s
  • Support CPU TDP 70-205W
  • Up to 28 Cores

System Memory

Memory Capacity
  • 24 DIMM slots
  • Up to 6TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM
  • Supports Intel® Optane™ DCPMM
Memory Type 2933/2666/2400/2133MHz ECC DDR4 RDIMM/LRDIMM

On-Board Devices

Chipset Intel® C622 chipset
SATA SATA3 (6Gbps) with RAID 0, 1, 5, 10
Network Controllers Dual Port 10GbE from C622
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Graphics ASPEED AST2500 BMC

Input / Output

SATA 10 SATA3 (6Gbps) ports
LAN
  • 2 RJ45 10GBase-T LAN ports
  • 1 RJ45 Dedicated IPMI LAN port
USB 4 USB 3.0 ports (rear)
Video 1 VGA Connector
COM Port 1 COM port (header)

Form Factor

4U Rackmountable with Rail kit

Dimensions

Height 7.0" (178mm)
Width 17.6" (447mm)
Depth 29" (737mm)
Weight
  • Net Weight: 65.5 lbs (29.7 kg)
  • Gross Weight: 100 lbs (45.3 kg)

Drive Bays / Storage

Hot-swap
  • Up to 24x 2.5" SAS/SATA drive bays
  • 8x 2.5" SATA supported natively
  • 2x 2.5" U.2 NVMe supported natively
 M.2
  • 1 NVMe based M.2 SSD
  • Form Factors: 2260, 2280, 22110

Expansion Slots

PCI-Express
  • 11 PCI-E 3.0 x16 (FH, FL) slots
  • 1 PCI-E 3.0 x8 (FH, FL, in x16) slot

System Cooling

Fans 8 Hot-swap 92mm cooling fans

Power Supply

2000W Redundant Power Supplies with PMBus
Total Output Power
  • 1000W: 100 - 120Vac
  • 1800W: 200 - 220Vac
  • 1980W: 220 - 230Vac
  • 2000W: 230 - 240Vac
  • 2000W: 200 - 240Vdc (UL/CUL only)

OS Compatibility

  • Ubuntu 16.04 LTS (x64) or later Ubuntu 18.04 LTS (x64) or later
  • Red Hat Enterprise Linux 7.4 (x86_64) or later
  • Windows Server 2016
  • Windows Server 2019
  • Citrix Xenserver 7.1.0 CU2 or later

Operating Environment

RoHS RoHS Compliant
Environmental Spec.
  • Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F)
  • Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
  • Operating Relative Humidity: 8% to 90% (non-condensing)
  • Non-operating Relative Humidity: 5% to 95% (non-condensing)

WinFast GS4830AT
OS Language Version Description
BIOS
Multilanguage3.3
( 2020/7/2 )		BIOS
Total size: [ 17235 KB ] 		download
VGA driver

10 64bit		MultilanguageNull
( 2020/7/24 )		Aspeed AST2400/AST2500 Graphic Driver
Total size: [ 55594 KB ] 		download
LAN driver

10 64bit		Multilanguage25.0
( 2020/7/23 )		Intel LAN Driver (All)
Total size: [ 540717 KB ] 		download
Chipset driver

10 64bit		Multilanguagev10.1.2.86
( 2020/7/24 )		Intel Chipset Driver
Total size: [ 3236 KB ] 		download
USB driver

10 64bit		Multilanguage4.0.0.36
( 2020/7/1 )		USB 3.0 driver
Total size: [ 5405 KB ] 		download
SATA Driver

10 64bit		MultilanguageNull
( 2020/7/24 )		Intel PCH Driver(SATA)
Total size: [ 412 KB ] 		download
SATA Utility

10 64bit		Multilanguage 6.1.0.1247
( 2020/7/24 )		 Intel Utility (SATA)
Total size: [ 45662 KB ] 		download
MS.Net_Framework

10 64bit		Multilanguage3.5
( 2020/7/9 )		MS.Net_Framework
Total size: [ 68248 KB ] 		download

10 64bit		Multilanguage4.5.2
( 2020/7/1 )		MS.Net_Framework_4.5.2
Total size: [ 337141 KB ] 		download

WinFast GS4830AT
Language Version Description
User's Manual
EnglishA
( 2020/7/24 )		User's Manual
Total size: [ 33174 KB ] 		download
Installing the RAID driver during Windows
EnglishA
( 2020/7/24 )		RAID_driver_installation_Guide
Total size: [ 38 KB ] 		download
