WinFast GS4845

  • Optimized for AI/Deep Learning GPU peering
  • Supports 8 double-wide GPU cards
  • Support PCI-E 4.0 and up to 8TB system memory

Key Features


  • Dual AMD EPYC™ 7002/7003 Series Processors
  • 32 DIMMs; up to 8TB 3DS ECC DDR4-3200MHz RDIMM/LRDIMM
  • 10 PCI-E 4.0 x16 (FH, FL) slots
    1 PCI-E 4.0 x8 slot
  • Support up to 8 pcs of Double-width GPU
  • Dual 1GBase-T LAN ports
  • Up to 24 Hot-swap 2.5" drive bays
  • 8 Hot-swap 92mm cooling fans
  • 2000W (2+2) Redundant Power
    Supplies Titanium Level (96%+)

2nd Gen AMD EPYC™
High Frequency Processors

Make the most of your
enterprise software investment

A balanced and optimized IT infrastructure, workload acceleration, and data protection is a must for enterprises to be competitive. AMD has been on the forefront of solving these challenges by delivering leadership innovations. The new AMD EPYC™ 7Fx2 Series Processors provide businesses advanced security features and ground-breaking performance with Hyper Converged Infrastructure (HCI), Databases (DB) and Commercial High Performance Computing (HPC) applications – enabling faster business insights and time to volume while helping optimize TCO.

PCIe® 4.0 doubles the data transfer speed over the previous generation

PCIe 4.0 delivers double the I/O performance over PCIe 3.0. You can use 128 lanes of I/O to double the network bandwidth that ties together HPC clusters and satisfies voracious needs for east-west bandwidth. For other application needs and in virtualized environments, you can connect with higher speed to GPU accelerators, NVMe drives.

Cooling System

High efficiency cooling system-5x Heavy duty fans with Optimal Fan Speed Control, for less power and ensure a stable environment and availability 24/7.

SATA vs NVMe

System Health Monitoring

The system has an onboard Baseboard Management Controller (BMC)
chip that supports system health monitoring.

Onboard Voltage Monitors

The onboard voltage monitor will continuously scan crucial voltage levels. Once a voltage becomes unstable, it will give a warning or send an error message to the IPMI WebGUI and IPMIView. Real time readings of these voltage levels are all displayed in IPMI.

Fan Status Monitor with Firmware Control

The system health monitor embedded in the BMC chip can check the RPM status of the cooling fans. The CPU and chassis fans are controlled via lPMI.

Environmental Temperature Control

System Health sensors in the BMC monitor the temperatures and voltage settings of onboard processors and the system in real time via the IPMI interface. Whenever the temperature of the CPU or the system exceeds a user-defined threshold, system/CPU cooling fans will be turned on to prevent the CPU or the system from overheating.

System Resource Alert

This feature is available when used with SuperDoctor 5. SuperDoctor 5 is used to notify the user of certain system events. For example, you can configure SuperDoctor 5 to provide you with warnings when the system temperature, CPU temperatures, voltages and fan speeds go beyond a predefined range3.

Applications


Manufacturing

Manufacturing

Model, simulate, test, and improve products like never before. With WinFast Workstation manufacturers can design and bring innovative products to market faster.
Media & Entertainment

Media & Entertainment

From pre-vis to post-production, the industry's most critically-acclaimed feature films require the latest technological advancements. WinFast Workstation works behind the scenes giving you the precision and power to tell remarkable stories.
Architecture

Architecture, Engineering and Construction

Workflows in the architecture, engineering, and construction (AEC) space are in transformation. Leading-edge technologies, powered by WinFast Workstation , are enabling AEC teams to optimize design workflows and build for the future.

AI Applications


CONSUMER INTERNET

CONSUMER INTERNET

Ad Personalization Click Through Rate Optimization Churn Reduction.
OIL & GAS

OIL & GAS

Sensor Data Tag Mapping Anomaly Detection Robust Fault Prediction.
FINANCIAL SERVICES

FINANCIAL SERVICES

Claim fraud Customer Service Chatbots/Routing Risk Evaluation.
MANUFACTURING

MANUFACTURING

Remaining Useful Life Estimation Failure Prediction Demand Forecasting.
HEALTHCARE

HEALTHCARE

Improve Clinical Care Drive Operational Effeciency Speed Up Drug Discovery.
TELECOM

TELECOM

Detect Network/Security/Anomalies Forecasting Network Performance Network Resource Optimization (SON).
RETAIL

RETAIL

Supply Chain and Inventory Management Price Management/Markdown Optimization Promotion Prioritization and Ad Targeting.
AUTOMOTIVE

AUTOMOTIVE

Personalization & Intelligent Custoemr Interactions Connected Vehicle Predictive Maintenance Forecasting, Demand and Capacity Planning.
Smart Home

SMART HOME

AI Speaker, Lighting, Security AI Appliances, Thrtmostat AI Vauums.

Leadtek AI Management Software

Leadtek GPU Docker Management System (GDMS) is a Docker-based GPU resource allocation and management software. GDMS uses an intuitive and graphical user interface to centrally manage AI and big data projects and development resources for universities/schools, research institutions, and corporations.

Processor

CPU
  • Dual AMD EPYC™ 7002/7003 Series Processors
  • Socket SP3
  • Supports CPU TDP up to 280W*
  • Up to 128 Cores (64 per CPU)

System Memory

Memory Capacity
  • 32 DIMM slots
  • Up to 8TB 3DS ECC DDR4-3200MH RDIMM/LRDIMM
  • * Minimum 4 DIMMs per CPU required with EPYC 7003 Series processors
Memory Type 3200MHz ECC DDR4 RDIMM/LRDIMM

On-Board Devices

Chipset System on Chip (SoC)
SATA SATA3 (6Gbps)
Network Controllers Provided via riser card
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Graphics ASPEED AST2500 BMC

Input / Output

SATA 24 SATA3 (6Gbps) ports
LAN
  • 2 RJ45 GBase-T LAN ports
  • 1 RJ45 Dedicated IPMI LAN port
USB 2 USB 3.2 Gen1 ports (rear)
Video 1 VGA Connector
COM Port 1 COM port (header)

Form Factor

4U Rackmountable with Rail kit

Dimensions

Height 7.0" (178mm)
Width 17.2" (437mm)
Depth 29" (737mm)
Weight
  • Net Weight: 65.5 lbs (29.7 kg)
  • Gross Weight: 100 lbs (45.3 kg)

Drive Bays / Storage

Hot-swap
  • Up to 24x 2.5" SAS/SATA drive bays
  • 4x 2.5" SATA supported natively
  • 4x 2.5" NVMe supported natively

Expansion Slots

PCI-Express 9 PCI-E 4.0 x16 (FHFL) slots or 10 PCI-E 4.0 x16 (FHFL) slots without NVMe devices

System Cooling

Fans 8 Hot-swap 92mm cooling fans.

Power Supply

2000W Redundant Power Supplies with PMBus
Total Output Power
  • 1000W: 100 – 127Vac
  • 1800W: 200 – 220Vac
  • 1980W: 220 – 230Vac
  • 2000W: 230 – 240Vac
  • 2000W: 220 – 240Vac (UL only)

OS Compatibility

  • Ubuntu 18.04 LTS (x64) or later
  • Ubuntu 20.04 LTS (x64) or later
  • Red Hat Enterprise Linux 8.1-8.x
  • Windows Server 2016
  • Windows Server 2019
  • Citrix Hypervisor 8.1 or later

Operating Environment

RoHS RoHS Compliant
Environmental Spec.
  • Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F)
  • Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
  • Operating Relative Humidity: 8% to 90% (non-condensing)
  • Non-operating Relative Humidity: 5% to 95% (non-condensing)

WinFast GS4845
OS Language Version Description
BIOS
English2.0
( 2021/8/5 )		BIOS
Total size: [ 12380 KB ] 		download
VGA driver

2019		English1.10
( 2021/8/5 )		Aspeed AST2500 Graphic Driver
Total size: [ 57569 KB ] 		download
LAN driver

2019		English 26.2
( 2021/8/5 )		Intel LAN Driver (ALL)
Total size: [ 693635 KB ] 		download
Chipset driver

2019		English 2.10.09.156
( 2021/8/5 )		AMD SP3 IO driver
Total size: [ 33061 KB ] 		download
Serial ATA RAID driver
LinuxEnglishNull
( 2021/8/5 )		Marvell RAID management utility
Total size: [ 187929 KB ] 		download
MS.Net_Framework

2019		English4.8
( 2021/8/5 )		Microsoft .Net Framework 4.8
Total size: [ 114531 KB ] 		download

WinFast GS4845
Language Version Description
User's Manual
EnglishNull
( 2021/1/5 )		User's Manual
Total size: [ 35873 KB ] 		download
DM
English1.2
( 2021/9/10 )		EDM
Total size: [ 329 KB ] 		download
(日本語)1.2
( 2021/9/10 )		EDM
Total size: [ 1114 KB ] 		download
(简体中文)1.2
( 2021/9/10 )		EDM
Total size: [ 422 KB ] 		download
(繁體中文)1.2
( 2021/9/10 )		EDM
Total size: [ 439 KB ] 		download
