WinFast WS750

    •
  • Entry-Level Workstation
  • Designed for AI/Deep learning/CAD and 3D Modeling
  • Support 1 NVIDIA Double-Width GPUs

Optimized for

  • AI / Deep Learning
  • 2D/3D and CAD Applications
  • 3D Simulation and Rendering
  • Digital Content Creation
  • 1 GPU support

Key Features


  • Single Socket V (LGA-1700) 14th /13th / 12th Generation Intel® Core™ Processors , TDP up to 125W
  • 4 DIMM slots, up to 128GB: 4x 32 GB DRAM
    Memory Type: 4400~4800MHz ECC DDR5 UDIMM
  • 2 PCI-E 5.0 x16 slots (16/NA or 8/8)
    2 PCI-E 3.0 x4
    1 5V PCI 32bit
    3 M.2 Interface: PCI-E 4.0 x4
  • Support 1 NVIDIA Quadro/GeForce card
  • 1x 2.5GbE BaseT with Intel® i225V
    1x 1GbE BaseT with Intel® i219LM
  • 4 3.5" SATA drive bays
    2 Standard 5.25" drive bays
    4 2.5” SATA drive bays (Optional)
  • 668W 80PLUS Platinum Power Supply

14th/13th/12th Gen Intel® Processors for Workstation
Features at a Glance

Performance Hybrid Architecture

Performance hybrid architecture, combining Performance-cores (P-cores) and Efficient-cores (E-Cores) to deliver balanced single-thread and multi-threaded real-world performance.

Intel® Thread Director

Optimizes workloads by helping the OS scheduler intelligently distribute workloads to the optimal cores.

PCIe 5.0 up to 16 Lanes

Offers readiness for up to 32 GT/s for fast access to peripheral devices and networking with up to 16 PCI Express 5.0 lanes.

PCIe 4.0 up to 4 Lanes

Offers up to 16 GT/s for fast access to peripheral devices and networking with up to 4 PCI Express 4.0 lanes.

Up to DDR5 4800 MT/s

This industry first memory technology supports fast frequencies and high bandwidth and throughput leading to enhanced workflow and productivity.

PCIe® 5.0 doubles the data transfer speed over the previous generation

PCIe 5.0 delivers double the I/O performance over PCIe 4.0. You can use 128 lanes of I/O to double the network bandwidth that ties together HPC clusters and satisfies voracious needs for east-west bandwidth. For other application needs and in virtualized environments, you can connect with higher speed to GPU accelerators, NVMe drives.

Blazing-Fast PCIe NVMe

Up to 10.6X performance than SATA

System Health Monitoring

The system has an onboard Baseboard Management Controller (BMC)
chip that supports system health monitoring.

Onboard Voltage Monitors

The onboard voltage monitor will continuously scan crucial voltage levels. Once a voltage becomes unstable, it will give a warning or send an error message to the IPMI WebGUI and IPMIView. Real time readings of these voltage levels are all displayed in IPMI.

Fan Status Monitor with Firmware Control

The system health monitor embedded in the BMC chip can check the RPM status of the cooling fans. The CPU and chassis fans are controlled via lPMI.

Environmental Temperature Control

System Health sensors in the BMC monitor the temperatures and voltage settings of onboard processors and the system in real time via the IPMI interface. Whenever the temperature of the CPU or the system exceeds a user-defined threshold, system/CPU cooling fans will be turned on to prevent the CPU or the system from overheating.

System Resource Alert

This feature is available when used with SuperDoctor 5. SuperDoctor 5 is used to notify the user of certain system events. For example, you can configure SuperDoctor 5 to provide you with warnings when the system temperature, CPU temperatures, voltages and fan speeds go beyond a predefined range3.

Optional software

Applications


Manufacturing

Manufacturing

Model, simulate, test, and improve products like never before. With WinFast Workstation manufacturers can design and bring innovative products to market faster.
Media & Entertainment

Media & Entertainment

From pre-vis to post-production, the industry's most critically-acclaimed feature films require the latest technological advancements. WinFast Workstation works behind the scenes giving you the precision and power to tell remarkable stories.
Architecture

Architecture, Engineering and Construction

Workflows in the architecture, engineering, and construction (AEC) space are in transformation. Leading-edge technologies, powered by WinFast Workstation , are enabling AEC teams to optimize design workflows and build for the future.

AI Applications


CONSUMER INTERNET

CONSUMER INTERNET

Ad Personalization Click Through Rate Optimization Churn Reduction.
OIL & GAS

OIL & GAS

Sensor Data Tag Mapping Anomaly Detection Robust Fault Prediction.
FINANCIAL SERVICES

FINANCIAL SERVICES

Claim fraud Customer Service Chatbots/Routing Risk Evaluation.
MANUFACTURING

MANUFACTURING

Remaining Useful Life Estimation Failure Prediction Demand Forecasting.
HEALTHCARE

HEALTHCARE

Improve Clinical Care Drive Operational Effeciency Speed Up Drug Discovery.
TELECOM

TELECOM

Detect Network/Security/Anomalies Forecasting Network Performance Network Resource Optimization (SON).
RETAIL

RETAIL

Supply Chain and Inventory Management Price Management/Markdown Optimization Promotion Prioritization and Ad Targeting.
AUTOMOTIVE

AUTOMOTIVE

Personalization & Intelligent Custoemr Interactions Connected Vehicle Predictive Maintenance Forecasting, Demand and Capacity Planning.
Smart Home

SMART HOME

AI Speaker, Lighting, Security AI Appliances, Thrtmostat AI Vauums.

Leadtek AI Management Software

Leadtek GPU Docker Management System (GDMS) is a Docker-based GPU resource allocation and management software. GDMS uses an intuitive and graphical user interface to centrally manage AI and big data projects and development resources for universities/schools, research institutions, and corporations.

Processor

CPU
  • Single Socket V (LGA-1700)
  • 14th / 13th / 12th Generation Intel® Core™ Processors
  • Support CPU TDP 125W
  • Up to 16(8+8) cores

System Memory

Memory Capacity
  • 4 DIMM slots
  • Memory Capacity: Up to 128GB
Memory Type 4400~4800MHz ECC DDR5 UDIMM

On-Board Devices

Chipset Intel® W680
SATA 8 SATA3 (6 Gbps) ports, RAID 0/1/5/10 support
Network Controllers
  • 1 RJ45 Gigabit Ethernet LAN port
  • 1 RJ45 2.5 Gigabit Ethernet LAN port

Input / Output

SATA 8 SATA3 (6Gbps) ports
NVMe 3 NVMe support with M.2 Socket
LAN 1 RJ45 GbE and 1 RJ45 2.5GbE LAN ports
USB
  • 3 USB 3.2 Gen 1 port(s) (2 front Type A; 1 front Type C)
  • 3 USB 3.2 Gen 2x1 port(s) (3 rear Type A)
  • 1 USB 3.2 Gen 2x2 port(s) (1 rear Type C)
Video
  • 1 DisplayPort 1.4a, 1 HDMI 2.0b Port
  • 1 Digital Video Interface (DVI-D)
Audio 7.1 HD Audio with optical S/PDIF

Form Factor

Mid-Tower

Dimensions and Weight

Height 16.7" (424mm)
Width 7.6" (193mm)
Depth 21.1" (536mm)
Weight Gross Weight: 30 lbs (13.61 kg)

Drive Bays / Storage

  • 4x 3.5" SATA (NVMe optional) drive bays
  • 2x 5.25" drive bays
  • 4x 2.5” drive bays(Optional)
  • 3 M.2 (M-key, 2280)

Expansion Slots

PCI-Express
  • 2x PCI-E 5.0 x16 running at NA/16 or 8/8
  • 2x PCI-E 3.0 x4 slot
  • 1x PCI slot
M.2
  • 3x M.2 Interface: PCI-E 4.0 x4
  • M.2 Form Factor: 2280
  • M.2 Key: M-Key

System Cooling

Fans
  • 1x 12cm rear exhaust fan
  • 1x 12cm front cooling fan (Optional)

Power Supply

668W 80PLUS Platinum Power Supply
AC Input 100-240Vac / 50-60Hz

OS Compatibility

  • Windows 10/11
  • Ubuntu 20.10

Operating Environment

RoHS RoHS Compliant
Environmental Spec.
  • Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F)
  • Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
  • Operating Relative Humidity: 8% to 90% (non-condensing)
  • Non-operating Relative Humidity: 5% to 95% (non-condensing)

WinFast WS750
OS Language Version Description
VGA driver

10
11		Multilanguage1.13/ 1.14
( 2023/3/24 )		ASPEED Graphic AST2400/2500/2600
Total size: [ 54932 KB ] 		download
LAN driver

10
11		Multilanguage28.0
( 2023/3/24 )		Intel LAN
Total size: [ 796125 KB ] 		download
Intel ME

10 64bit		Multilanguage2.0.3-0004
( 2023/3/24 )		Intel QAT
Total size: [ 38284 KB ] 		download
INF

10
11		English10.1.19485.8386
( 2023/7/3 )		Intel INF
Total size: [ 3899 KB ] 		download
MS.Net_Framework

10
11		Multilanguage3.5
( 2023/3/24 )		Microsoft .Net Framework 3.5 Redistributable for Windows
Total size: [ 201720 KB ] 		download

10
11		Multilanguage6.0.302
( 2023/3/24 )		Microsoft .Net SDK
Total size: [ 200655 KB ] 		download

10
11		Multilanguage4.8
( 2023/3/24 )		Microsoft .Net Framework 4.8
Total size: [ 114531 KB ] 		download
Intel VROC

10
11		Multilanguage8.0.0.4035
( 2023/7/3 )		Intel VROC
Total size: [ 29194 KB ] 		download

WinFast WS750
Language Version Description
User's Manual
EnglishA
( 2023/3/24 )		User's Manual
Total size: [ 16687 KB ] 		download
  • Revised web page of product spec and information won't be noticed, product colorbox printing shows the actual information of the product.
  • Above product spec is for reference only, actual spec rely on the real product and Leadtek keeps the right to alter. Each sales region will impacts the product difference, please contact your supplier for making sure the actual product information.
  • The adapter, cable and software listed on the web page are for reference only and Leadtek keeps the right to alter, revised information won't be noticed.
  • Above brand name and product name are trademark of each corresponding company.
