WinFast WS945

  • NVIDIA-Certified Workstation
  • High-end Workstation
  • •High Performance Computing
  • Ideal for 3D Simulation and Rendering, Digital Content Creation, AI/Deep Learning

Key Features

  • Single AMD Ryzen™ Threadripper™ PRO 3000WX
    Series processor, Socket sWRX8/SP3
    Supports CPU TDP up to 280W
  • 4x fixed internal 3.5"/2.5" SATA drive bays,
    2x fixed front 2.5" SATA drive bays,
    4x M.2
  • Support up to 4 Double-width GPUs
  • 2000W Platinum Level Power Supply
  • 6x PCI-E 4.0 x16 slots,
    M.2 Interface: 4x PCI-E 4.0 x4,
    M.2 Form Factor: 2280/22110
    M.2 Key: M-Key
    U.2 Interface: 2x U.2 sockets (Software RAID 0,1)
  • Up to 2TB Registered ECC DDR4 3200-MHz Memory; in 8 DIMM slots.
  • 1x 10GBase-T and 1x 1GbE LAN(shared with IPMI) ports

Multiple GPU support

WinFast WS945 features a powerful GPU architecture that supports up to 4 double-width GPUs in a 5U workstation, including NVIDIA® A6000/A5000/A4000, Quadro RTX8000/RTX6000/RTX5000®, enable scaling of performance in order to meet the demands of AI, high-performance computing, and 3D rendering applications.

PCIe® 4.0 doubles the data transfer speed over the previous generation

PCIe 4.0 delivers double the I/O performance over PCIe 3.0. You can use 128 lanes of I/O to double the network bandwidth that ties together HPC clusters and satisfies voracious needs for east-west bandwidth. For other application needs and in virtualized environments, you can connect with higher speed to GPU accelerators, NVMe drives.

SATA vs NVMe

Up to 5.3X performance than SATA

System Health Monitoring

The system has an onboard Baseboard Management Controller (BMC)
chip that supports system health monitoring.

Onboard Voltage Monitors

The onboard voltage monitor will continuously scan crucial voltage levels. Once a voltage becomes unstable, it will give a warning or send an error message to the IPMI WebGUI and IPMIView. Real time readings of these voltage levels are all displayed in IPMI.

Fan Status Monitor with Firmware Control

The system health monitor embedded in the BMC chip can check the RPM status of the cooling fans. The CPU and chassis fans are controlled via lPMI.

Environmental Temperature Control

System Health sensors in the BMC monitor the temperatures and voltage settings of onboard processors and the system in real time via the IPMI interface. Whenever the temperature of the CPU or the system exceeds a user-defined threshold, system/CPU cooling fans will be turned on to prevent the CPU or the system from overheating.

System Resource Alert

This feature is available when used with SuperDoctor 5. SuperDoctor 5 is used to notify the user of certain system events. For example, you can configure SuperDoctor 5 to provide you with warnings when the system temperature, CPU temperatures, voltages and fan speeds go beyond a predefined range3.

Applications


Manufacturing

Manufacturing

Model, simulate, test, and improve products like never before. With WinFast Workstation manufacturers can design and bring innovative products to market faster.
Media & Entertainment

Media & Entertainment

From pre-vis to post-production, the industry's most critically-acclaimed feature films require the latest technological advancements. WinFast Workstation works behind the scenes giving you the precision and power to tell remarkable stories.
Architecture

Architecture, Engineering and Construction

Workflows in the architecture, engineering, and construction (AEC) space are in transformation. Leading-edge technologies, powered by WinFast Workstation , are enabling AEC teams to optimize design workflows and build for the future.

AI Applications


CONSUMER INTERNET

CONSUMER INTERNET

Ad Personalization Click Through Rate Optimization Churn Reduction.
OIL & GAS

OIL & GAS

Sensor Data Tag Mapping Anomaly Detection Robust Fault Prediction.
FINANCIAL SERVICES

FINANCIAL SERVICES

Claim fraud Customer Service Chatbots/Routing Risk Evaluation.
MANUFACTURING

MANUFACTURING

Remaining Useful Life Estimation Failure Prediction Demand Forecasting.
HEALTHCARE

HEALTHCARE

Improve Clinical Care Drive Operational Effeciency Speed Up Drug Discovery.
TELECOM

TELECOM

Detect Network/Security/Anomalies Forecasting Network Performance Network Resource Optimization (SON).
RETAIL

RETAIL

Supply Chain and Inventory Management Price Management/Markdown Optimization Promotion Prioritization and Ad Targeting.
AUTOMOTIVE

AUTOMOTIVE

Personalization & Intelligent Custoemr Interactions Connected Vehicle Predictive Maintenance Forecasting, Demand and Capacity Planning.
Smart Home

SMART HOME

AI Speaker, Lighting, Security AI Appliances, Thrtmostat AI Vauums.

Leadtek AI Management Software

Leadtek GPU Docker Management System (GDMS) is a Docker-based GPU resource allocation and management software. GDMS uses an intuitive and graphical user interface to centrally manage AI and big data projects and development resources for universities/schools, research institutions, and corporations.

Processor

CPU
  • Single AMD Ryzen™ Threadripper™ PRO 3000WX Series processor
  • Socket sWRX8/SP3
  • Supports CPU TDP up to 280W
  • Up to 64 Cores

System Memory

Memory Capacity
  • 8 DIMM slots
  • Up to 2TB 3DS ECC SDRAM
  • 8-channel memory bus
Memory Type 3200 MHz ECC DDR4 RDIMM/LRDIMM

On-Board Devices

Chipset AMD WRX80
SATA SATA3 (6Gbps); RAID 0/1/5/10 support
Network
  • 10G LAN: Single LAN via Marvel AQC110C 10G Ethernet Controller
  • 1GbE LAN: Single LAN with Intel® i210AT Enternet Controller (shared with IPMI)
IPMI Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support

Input / Output

SATA 4x SATA3 (6Gbps) ports
NVMe 4x M.2 Socket support NVMe
LAN 1x RJ45 10GBase-T and 1x RJ45 1GBase-T ports(shared with IPMI)
USB Front side:
1x USB 3.2 Gen 1 Type C
2x USB 3.2 Gen 1 Type A
2x USB 2.0
Rear side:
5x USB 3.2 Gen2 Type A
1x USB 3.2 Gen2x2 Type C
2x USB 3.2 Gen 1 Type A
Video 1x VGA port

Form Factor

5U Rackmountable / Tower Optional Rackmount Kit

Dimensions

Height 21.06" (535mm)
Width 8.74" (222mm)
Depth 22.56" (573mm)

Drive Bays / Storage

  • 4x internal fixed 3.5"/2.5" SATA3 drive bays
  • 2x front fixed 2.5" SATA3 drive bays
  • 2x 5.25" drive bays

Expansion Slots

PCI-Express 6x PCI-E 4.0 x16 slots
M.2
  • M.2 Interface: 4 PCI-E 4.0 x4
  • Form Factor: 2280, 22110
  • Key: M-Key
U.2
  • Interface: 2 U.2 Sockets
  • Software RAID 0,1 support

System Cooling

Fans
  • 1x 12cm rear exhaust fan
  • 3x 12cm front cooling fans (optional)
  • 3x 12cm top cooling fans (optional)

Power Supply

2000W PS/2 Multi-Output Power Supply
Total Output Power and Input
  • 1200W with Input 100 - 115Vac
  • 1500W with Input 115 - 200Vac
  • 2000W with Input 200 - 264Vac
AC Input Frequency 50-60Hz

OS Compatibility

  • Windows 10 64bit Enterprise
  • Windows 10 64bit Pro Workstations
  • RHEL 7.9/8.2/8.3 64bit
  • Ubuntu 20.04.1 64bit Desktop
  • VMWare ESXi 7.0u1 x64
  • Citrix XenServer 8.2

Operating Environment

RoHS RoHS Compliant
Environmental Spec.
  • Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F)
  • Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
  • Operating Relative Humidity: 8% to 90% (non-condensing)
  • Non-operating Relative Humidity: 5% to 95% (non-condensing)

WinFast WS945
OS Language Version Description
Audio driver

10 64bit		Multilanguage2299
( 2021/11/24 )		Realtek audio
Total size: [ 14242 KB ] 		download
VGA driver

10 64bit		Multilanguage1.10/1.12
( 2021/12/30 )		Aspeed AST2400/AST2500 Graphic Driver
Total size: [ 61376 KB ] 		download
LAN driver

10 64bit		Multilanguage26.2
( 2021/12/30 )		Intel LAN Driver (ALL)
Total size: [ 693635 KB ] 		download

10 64bit		Multilanguage3.1.3
( 2021/3/28 )		Marvel LAN
Total size: [ 907 KB ] 		download
Chipset driver

10 64bit		Multilanguage3.08.06.148
( 2021/12/30 )		AMD WRX8 Chipset driver
Total size: [ 49594 KB ] 		download
MS.Net_Framework

10 64bit		Multilanguage4.8
( 2021/4/15 )		Microsoft .Net Framework 4.8
Total size: [ 114531 KB ] 		download

WinFast WS945
Language Version Description
User's Manual
EnglishA
( 2021/12/30 )		User's manual
Total size: [ 17909 KB ] 		download
DM
(繁體中文)1.2
( 2021/9/13 )		EDM
Total size: [ 404 KB ] 		download
English1.2
( 2021/9/13 )		EDM
Total size: [ 324 KB ] 		download
(简体中文)1.2
( 2021/9/13 )		EDM
Total size: [ 380 KB ] 		download
(日本語)1.2
( 2021/9/13 )		EDM
Total size: [ 1063 KB ] 		download
