Ultra-Secure, Easy to Manage and Dual-Display Clients Optimized for a VMware or Amazon WorkSpaces Environment
8 Editions
Do it all with total security. The era of complex, non-secure PC solutions is almost over. Leadtek PCoIP-enabled virtual desktop solution, on the other hand, enables all computing resources and data to be transferred to a centralized server in a secure data center and lowers support overheads for the enterprise. This enhances enterprise data management and security while delivering an immaculate, uncompromised end user experience over standard IP networks.
PCoIP zero client makes it possible to deliver workstation class performance for professional applications including 3D CAD/CAM, Digital Content Creation, video editing and advanced knowledge worker level business software.
Centralize CAD Data Files, Secure Remote Access, Heat & Noise Elimination
Build Render Cluster, Prevent Intellectual Property Loss, Support Off-Shore Contract Workers
Security and High-resolution & Lossless Medical Images
Security, Multiple Display and Easy Recovery
Offers industry-leading low power consumption design and engineering technology. The net result is a small, quiet, low power (average power consumption 6W) ) and reliable device that requires minimal IT administration and support. Additionally, we give it super slim look - less than 2.69 cm ! its ultra-light (600g) and slim design is perfect for users with limited working space. Thanks to the space-saving and noiseless features, users will hardly notice it on their office desks.
Support up to six USB, a Microphone, a Headphone, an optional smart card reader, and Ethernet connectors
Compatible with VMware Horizon, Teradici All Access solutions, Amazon WorkSpaces, Azure, Google Cloud Platform, on-premise data centers, and PCoIP remote workstation cards.
PCoIP solution allows ALL desktop computing hardware, including existing PCs, workstations, and servers, to be moved into a secure location. PCoIP transmits pixels - NOT data - so all data stays secure in your datacenter.
PCoIP zero clients simply receive and decode encrypted image information, do not store any application data, and are immune to viral attack. It uses high standard AES 256 and NSA Suite B ciphers encryption. And extensive USB security and authentication features are provided.
As a result of collaboration with VMware, VMware Horizon View incorporates PCoIP technology as the remote desktop protocol for virtual desktops, providing a significantly better user experience than is provided with other remoting protocols. Corporations deploying VMware Horizon View’s latest versions can achieve all of the advantages of virtual desktop deployments with all of the advantages of the PCoIP protocol and with the manageability and performance advantages of PCoIP zero clients.
Support up to DisplayPort display at 3840x2160, or two 1920x1200 resolution and the highest pixel processing power.
With PCoIP technology, your enterprise applications can be located and managed in the cloud or in your data center while your users continue to enjoy premium interactive experience with their desktops and applications.
PCoIP sessions are established from PCoIP hardware zero clients to workstations with PCoIP remote workstation host cards for full workstation-class performance
PCoIP sessions are established from VMware Horizon View servers or Amazon WorkSpaces with the PCoIP protocol integrated to deliver enhanced security and performance.
Leadtek PCoIP products are the only remoting solution that puts absolutely no load on the host CPU or graphics card, so CPU/GPU can devote all its energy for full-featured graphics. Maximum performance of 130 mega pixels per second (Mpps) capable of driving full screens of changing pixels or application refresh rates up to 60 frames per second (fps) ensures the best remote user experience.
Unlike traditional thin clients which are basically small PCs running a version of Windows or Linux, Leadtek PCoIP products are the only true zero clients that have no CPU, no operating system (no Windows or Linux), no device drivers, no hard drive, no fan, no noise, etc. This means it requires no OS patches, no driver updates or virus signature files. Once it's set up, users never have to touch it again.
| PC | PCoIP Zero Client  |
|
|---|---|---|
| OS Restricted | YES | NO |
| CPU | YES | NO |
| Hardware Drivers | YES | NO |
| Control Response | Fast | Fast |
| Graphics Performance | Great | Great * |
| Applications | Great | Great |
| Virus and Spyware | YES | NO ** |
| IT Management | Heavy | Easy |
| Power Consumption | High | Ultra Low |
| Noise | High | Noiseless |
| Security | Poor | Great |
IT system requires authentication of users and is commonly done with passwords. Because of the value and confidentiality of information in the financial institutions as well as enterprises and governments, protecting intellectual property, IT system, and employee identity credentials has always been a priority.
Leadtek optional high-performance Smart Card Reader that is compliant with all industry standards and is compatible with virtually any contact smart card and a variety of applications
| Model | TERA1100 Series | TERA2140 Series | TERA2321 Series |
| Max Number of Displays | 2 | 4 | 2 |
| Processor | TERA1100 | TERA2140 | TERA2321 |
| Imaging Performance | 10 Mpps (VDI) 100 Mpps (Workstation)* |
50 Mpps (VDI) 250 Mpps (Workstation)* |
50 Mpps (VDI) 130 Mpps (Workstation)* |
| Maximum Resolution | Two 1920x1200 | Two 3840x2160 (DP model only)*** Two 2560x1600 Four 1920x1200 |
One 3840x2160 (DP model only)*** One 2560x1600 Two 1920x1200 |
| Memory Type | 128 MB XDR |
512 MB DDR3 |
|
| Device Physical Dimensions | 6.89 (height) x 5.20 (length) x 1.42 (thinness) inches without stand | 6.85 (height) x 5.20 (length) x 1.81 (thinness) inches without stand |
6.77 (height) x 5.21 (length) x 1.06 (thinness) inches Contact us for details on our enclosures and their dimensions |
| Power Management | Partial | Full Wake-on-LAN and Wake-on-USB | |
| Typical Device Power | 12W | 12W | 6W |
| Encryption | AES-128/Salsa256 Suite B Ciphers (Workstation) |
AES-128/AES-256 Suite B Ciphers (Workstation) |
|
| Connectors | Single-link DVI-I connector | Single-link DVI-D or DisplayPort connector | Single-link DVI-D or DisplayPort connector |
| Second Single-link DVI-I connector | Second Single-link DVI-D or DisplayPort connector | Second Single-link DVI-I connector | |
| Two front USB connectors | Third Single-link DVI-D or DisplayPort connector | (or One Dual-link DVI-D with adapter) | |
| (Smart card reader zero clients have one front USB connector) | Forth Single-link DVI-D or DisplayPort connector | Two or four front USB 2.0 connectors** | |
| Two rear USB connectors | (or Two Dual-link DVI-D with adapters) | Two rear USB 2.0 connectors | |
| Smart Card Reader port (Optional) | Two front USB 2.0 connectors** | Smart Card Reader port (Optional) | |
| Headphone jack | (Smart card reader zero clients have one front USB connector) | Headphone jack | |
| Microphone jack | Two rear USB 2.0 connectors | Microphone jack | |
| Speaker jack | Smart Card Reader port (Optional) | Speaker jack (for Dual-DVI zero clients) | |
| RJ45 or Fiber Ethernet connector | Headphone jack | RJ45, RJ45 with PoE (Power-over-Ethernet), or Fiber Ethernet connector | |
| 12VDC Power jack | Microphone jack | 12VDC Power jack | |
| Speaker jack | |||
| RJ45 or Fiber Ethernet connector | |||
| 12VDC Power jack | |||
| LED | PCoIP LED | PCoIP LED | PCoIP LED |
| Zero Client Power Button LED | Zero Client Power Button LED | Zero Client Power Button LED | |
| Button | Zero Client Power Button | Zero Client Power Button | Zero Client Power Button |
| Remote PC Power Button | |||
| Thermal Cooling Solution | Passive heat sink | ||
| Operating System Support | Completely operating system independent | ||
| Package Content | PCoIP Zero Client | ||
| Power adaptor and power cord | |||
| Ethernet cable (Optional) | |||
| Dual-link DVI adapter cables (Optional for TERA2140 Quad-DVI and TERA2321 Dual-DVI zero clients) | |||
| Quick installation guide | |||
| VESA mount package (Optional) | |||
| TERA2321 DP+DVI Zero Client | ||||
|---|---|---|---|---|
| OS | Language | Version | Description |  |
| Utility | ||||
| English | 1.10.8 ( 2017/1/16 ) | Supporting Models :TERA2 and TERA1 Host Cards and Zero Clients PCoIP Management Console (PCoIPMC) enables administrators to centrally manage a PCoIP deployment. more Total size: [ 501553 KB ] |  | |
| Audio driver | ||||
 10 8 7 64bit | English | 1.2.2 ( 2018/10/19 ) | Supporting Models :The PCoIP Component Installer is supported on the following operating systems:
- Microsoft Windows 7 32 bit
- Microsoft Windows 7 64 bit
- Microsoft Windows 8 64 bit
- Microsoft Windows 10 64 bit Teradici Virtual Audio Driver more Total size: [ 929 KB ] | |
| Applications | ||||
| English | 2.2 ( 2016/2/16 ) | Supporting Models :TERA2 Zero Clients running firmware 4.7.1 or later The Teradici PCoIP Workstation Access Software is a software bundle that includes two host agents for different PCoIP deployment scenarios. The deskside scenario facilitates deployments that have a workstation with local monitor(s) attached. The datacenter/cloud scenario facilitates deployments that have a workstation (physical, virtualized, or in the cloud) with NO local monitor(s) attached. more Total size: [ 19081 KB ] | | |
| English | 2.3 ( 2016/2/16 ) | Supporting Models :TERA2 Zero Clients running firmware 4.7.1 or later The Teradici PCoIP Workstation Access Software is a software bundle that includes two host agents for different PCoIP deployment scenarios. The deskside scenario facilitates deployments that have a workstation with local monitor(s) attached. The datacenter/cloud scenario facilitates deployments that have a workstation (physical, virtualized, or in the cloud) with NO local monitor(s) attached. more Total size: [ 19359 KB ] | | |
| Firmware | ||||
| Multilanguage | 17.05.3 ( 2020/8/28 ) | Supporting Models :TERA2 Zero Clients PCoIP Zero Client Firmware 17.05.3 is a firmware release replacing firmware 5.5.2 for PCoIP Zero Clients (not PCoIP Remote Workstation Cards). This release is a maintenance release with bug fixes and security updates over release 5.5.2. Either zero client firmware 4.7.x or 4.8 must be used as the staging firmware prior to upgrading to firmware 17.05.3. Total size: [ 19276 KB ] | | |
| Multilanguage | 5.5.2 ( 2019/5/31 ) | Supporting Models :TERA2 Zero Clients Firmware 5.5.2 is only applicable to TERA2 Zero Clients. For TERA2 Host Cards, firmware 4.9.0 is the latest firmware release. Either zero client firmware 4.7.x or 4.8 must be used as the staging firmware prior to upgrading to firmware 5.5.2. Total size: [ 30859 KB ] | | |
| Multilanguage | 4.8.2 ( 2016/9/28 ) | Supporting Models :TERA2 Zero Clients Firmware 4.8.2 is only applicable to TERA2 Zero Clients. For TERA2 Host Cards and TERA1 products, firmware 4.9.0 is the latest firmware release. If zero clients have firmware 4.2.0 or earlier installed, then you will need to install firmware 4.6.0 in order to upgrade to 4.8.2. Total size: [ 34341 KB ] | | |
| Multilanguage | 4.8.0 ( 2015/4/8 ) | Supporting Models :TERA2 Zero Clients Firmware 4.8.0 is only applicable to TERA2 Zero Clients. For TERA2 Host Cards and TERA1 products, firmware 4.9.0 is the latest firmware release. If zero clients have firmware 4.2.0 or earlier installed, then you will need to install firmware 4.6.0 in order to upgrade to 4.8.0. Total size: [ 41226 KB ] | | |
| Multilanguage | 4.6.0 ( 2014/10/7 ) | Supporting Models :TERA2 Host Cards and Zero Clients This is a major release 4.6.0 installed on both the TERA2 Host and Zero Client. more Total size: [ 19340 KB ] | | |
| TERA2321 DP+DVI Zero Client | |||
|---|---|---|---|
| Language | Version | Description | |
| User's Manual | |||
| English | Issue 13 ( 2016/5/31 ) | This Administrators Guide helps you through the process to set up and configure your TERA2 products. Total size: [ 10309 KB ] | |
| Quick Guide | |||
| Multilanguage | A ( 2012/11/13 ) | Supporting Models :TERA2 Host Cards This Quick Start Guide will help you configure your TERA2 host card. Total size: [ 4218 KB ] | |
| Multilanguage | A ( 2016/3/2 ) | Supporting Models :TERA2 Zero Clients This Quick Start Guide will help you configure your TERA2 zero client. Total size: [ 2940 KB ] | |
| DM | |||
| (繁體中文) | 2015 ( 2015/5/4 ) | PCoIP產品型錄 Total size: [ 1757 KB ] | |
| English | 2017 ( 2017/5/12 ) | PCoIP product brochure Total size: [ 3803 KB ] | |
| Deployment Guide | |||
| English | 2.6 ( 2016/11/30 ) | Supporting Models :PCoIP host/client PCoIP Protocol Virtual Network Design Checklist more Total size: [ 536 KB ] | |
| English | Issue 3 ( 2013/1/31 ) | Using PCoIP Host cards with VMware View more Total size: [ 1405 KB ] | |
