EL2115 Ultra-Thin Client

High-Performance Thin Client with 4K UHD Capability, Security Design , and Productivity-maximizing features

EL2115

Ultra-Thin Client

8 Editions

Leadtek is specialized in designing and manufacturing truly astounding graphics performance, outstanding power efficiency, and remarkably reliable endpoint devices for VDI (Virtual Desktop Infrastructure) applications.

(Ultra-) Thin Client is targeted to users who request productivity-maximizing features and full ISV provider compatibility, including Citrix, VMware and Microsoft. You can choose the processing power appropriate for your productivity needs, whether it’s for graphics-intensive design or everyday office-based tasks.

  • Apply Intel x6211E System-on-Chip low-power integrated solution
  • Three 4K UHD (2x DP plus 1x DP over USB-C)
  • Five USB (2x USB 3.2, 1x Type-C and 2x USB 2.0) peripherals
  • DDR4 dual-channel SDRAM system memory and optional integrated smart card reader
  • Support Ethernet LAN or SFP Fiber, and optional wireless network

Leadtek Ultra-Thin Client is a book-size desktop device that applies low-power SoC with a very low power consumption of 6 watts and no need of fan for cooling. Additionally, we give it super slim look and slim design is perfect for users with limited working space. Thanks to the space-saving and noiseless features, users will hardly notice it on their office desks. Optional VESA Mount kit enables users to mount Thin Client behind the monitor, cleaning up more space for daily works.

VMware Ready and Citrix Ready Certified

Verified by VMware and Citrix, All Leadtek Ultra-Thin Clients with LvOS (Leadtek Thin Client OS) have proved fully compatible with latest VMware Horizon and Citrix Virtual Desktops and Apps. With pre-installed VMware Horizon Client and Citrix Workspace App in LvOS, major VDI solutions, including VMware with PCoIP & Blast Extreme, Citrix with HDX and Microsoft RemoteFX, are supported out of the box.

Leadtek Device Management Software and Thin Client OS
Keep Your Client Deployment Simple

Leadtek (Ultra-) Thin Client with LvOS (Leadtek Thin Client OS) can be managed by DMS (Leadtek Device Management Software), a free web-based management tool that allows administrators:

  • Centrally and remotely access and update the configuration of your client devices
  • Effectively apply the same configuration data to groups of devices
  • Easy deployment, troubleshooting, and view status information
  • Update settings and firmware via easy-to-use interface

LvOS is a virus-proof Linux OS that has no attraction to the malware attacks. With DMS security control, end-user misconfiguration is totally blocked. LvOS and DMS can further streamline the already minimal management of a VDI infrastructure.

  Three Display

Resolution up to
4K UHD

Support up to three 4096x2160 UHD (two display port plus one display port over USB-C), perception-free video outputs, and five USB (two USB 3.2 Gen2, one Type-C, and two USB 2.0) peripherals allows PC/workstation and server relocation to the datacenter or computer room without compromising end user experience or productivity

Network Adaptability with Gigabit Ethernet, SFP Fiber, and Optional Wireless

Leadtek (Ultra-) Thin Client features a high degree of connectivity with your choice of embedded networking interface in 10/100/1000 Mbps Ethernet LAN or 100/1000 Mbps SFP Fiber. It also supports optional dual-band WiFi and Bluetooth wireless so you can get connected when you need to.

DDR4 dual-channel
SDRAM system memory

Support dual-channel DDR4 memory, up to 3200 MT/s high-speed data transfer rate

Feature Integrated Smart Card Reader Authentication

IT system requires authentication of users. This identification is commonly done with passwords. Because of the value and confidentiality of information in the financial institutions as well as enterprises and governments, protecting intellectual property, IT system, and employee identity credentials has always been a priority. High-performance Smart Card Reader that is compliant with all industry standards and is compatible with virtually any contact smart card and a variety of applications.

Comparison

Product AL2115 Ultra-Thin Client AL4115 Ultra-Thin Client EL2115 Ultra-Thin Client EL4115 Ultra-Thin Client
Processor Intel N3350 SOC (1.1-2.4GHz dual-core) Intel x5-E3940 SOC (1.6-1.8GHz quad-core) Intel x6211E SOC (1.3-3.0GHz dual-core) Intel x6413E SOC (1.5-3.0GHz quad-core)
RAM Onboard 4GB/8GB LPDDR4 Onboard 4GB/8GB LPDDR4 Onboard 4GB/8GB LPDDR4 Onboard 4GB/8GB LPDDR4
Storage Non-removable eMMC, up to 32GB Non-removable eMMC, up to 32GB Non-removable eMMC (default 8GB or 32GB) Non-removable eMMC (default 8GB or 32GB)
Video Output Two DisplayPort Two DisplayPort Three DisplayPort* Three DisplayPort*
Maximum Resolution 3840x2160 UHD @ 60Hz (DP) 3840x2160 UHD @ 60Hz (DP) 4096x2160 UHD @ 60Hz (DP) 4096x2160 UHD @ 60Hz (DP)
USB Peripherals Six (4x USB 3.2, 2x USB 2.0) Six (4x USB 3.2, 2x USB 2.0) Five (2x USB 3.2 Gen2, 1x Type-C, 2x USB 2.0) Five (2x USB 3.2 Gen2, 1x Type C, 2x USB 2.0)
Audio Headphones / Microphone / Speaker (internal) Headphones / Microphone / Speaker (internal) Headphones / Microphone / Speaker (internal) Headphones / Microphone / Speaker (internal)
Network Connector RJ45 or SFP Fiber, optional wireless RJ45 or SFP Fiber, optional wireless RJ45 or SFP Fiber, optional wireless RJ45 or SFP Fiber, optional wireless
Authentication Optional smart card reader Optional smart card reader Optional smart card reader Optional smart card reader
OS Linux, Windows Linux, Windows Linux, Windows Linux, Windows
Thermal Cooling Solution Passive heat sink Passive heat sink Passive heat sink Passive heat sink
Kensington Security Slot Yes Yes Yes Yes
VESA Mount Support Yes Yes Yes Yes
Device Physical Dimensions 6.7 (height) x 5.2 (length) x 1.2 (thinness) inches without stand
Contact us for details on our enclosures and their dimensions		 6.7 (height) x 5.2 (length) x 1.2 (thinness) inches without stand
Contact us for details on our enclosures and their dimensions		 6.7 (height) x 5.2 (length) x 1.2 (thinness) inches without stand Contact us for details on our enclosures and their dimensions 6.7 (height) x 5.2 (length) x 1.2 (thinness) inches without stand
Contact us for details on our enclosures and their dimensions
TAA Compliance Yes Yes Yes Yes
Optional Wireless 2.4G and 5G dual-band 802.11 a/b/g/n/ac Wi-Fi (2T/2R) + Bluetooth 5.0 integrated wireless (Intel WiFi 5- AC 9260) with external dual antennas
Package Content (Ultra-) Thin Client
19V power adapter and power cord
Ethernet cable (optional)
Quick installation guide
Operating / Storage Environment Humidity
  • Relative (non-condensing): 10% to 90%
  • Storage: 5% to 95%
Temperature
  • Operational: 0 to 40 degree C
  • Storage: -20 to 70 degree C

*Note: EL2115/EL4115 support two display port plus one display port over USB-C

EL2115 Ultra-Thin Client
Language Version Description
DM
English2023
( 2023/4/26 )		(Ultra-)Thin Client product brochure
Total size: [ 3455 KB ] 		download
(繁體中文)2023
( 2023/4/26 )		簡型／精簡型電腦產品簡介
Total size: [ 1878 KB ] 		download
English2024
( 2024/2/6 )		Trusted Zero Client product brochure_Zero Trust solution
Total size: [ 1513 KB ] 		download
  • Revised web page of product spec and information won't be noticed, product colorbox printing shows the actual information of the product.
  • Above product spec is for reference only, actual spec rely on the real product and Leadtek keeps the right to alter. Each sales region will impacts the product difference, please contact your supplier for making sure the actual product information.
  • The adapter, cable and software listed on the web page are for reference only and Leadtek keeps the right to alter, revised information won't be noticed.
  • Above brand name and product name are trademark of each corresponding company.
